品牌:ABB
起订:1台
ACSM1机械类传动产品
输入电压: 三相AC380V~480V（+10%/-15%）；价格不含控制盘；防护等级IP20
04AS=风冷模块，速度和转矩控制
3ABD00024309 ACSM1-04AS-02A5-4
3ABD00024310 ACSM1-04AS-03A0-4
3ABD00024311 ACSM1-04AS-04A0-4
3ABD00024312 ACSM1-04AS-05A0-4
3ABD00024313 ACSM1-04AS-07A0-4
3ABD00024314 ACSM1-04AS-09A5-4
3ABD00024315 ACSM1-04AS-012A-4
3ABD00024316 ACSM1-04AS-016A-4
3ABD00024317 ACSM1-04AS-024A-4
3ABD00024318 ACSM1-04AS-031A-4
3ABD00024319 ACSM1-04AS-040A-4
3ABD00024320 ACSM1-04AS-046A-4
3ABD00024321 ACSM1-04AS-060A-4
3ABD00024322 ACSM1-04AS-073A-4
3ABD00024323 ACSM1-04AS-090A-4
04AM=风冷模块，运动控制
3ABD00024324 ACSM1-04AM-02A5-4
3ABD00024325 ACSM1-04AM-03A0-4
3ABD00024326 ACSM1-04AM-04A0-4
3ABD00024327 ACSM1-04AM-05A0-4
3ABD00024328 ACSM1-04AM-07A0-4
3ABD00024329 ACSM1-04AM-09A5-4
3ABD00024330 ACSM1-04AM-012A-4
3ABD00024331 ACSM1-04AM-016A-4
3ABD00024332 ACSM1-04AM-024A-4
3ABD00024333 ACSM1-04AM-031A-4
3ABD00024334 ACSM1-04AM-040A-4
3ABD00024335 ACSM1-04AM-046A-4
3ABD00024336 ACSM1-04AM-060A-4
3ABD00024337 ACSM1-04AM-073A-4
3ABD00024338 ACSM1-04AM-090A-4
04CS=冷却底板模块，速度和转矩控制
3ABD00024339 ACSM1-04CS-024A-4
3ABD00024340 ACSM1-04CS-031A-4
3ABD00024341 ACSM1-04CS-040A-4
3ABD00024342 ACSM1-04CS-046A-4
3ABD00024343 ACSM1-04CS-060A-4
3ABD00024344 ACSM1-04CS-073A-4
3ABD00024345 ACSM1-04CS-090A-4
04CM=冷却底板模块，运动控制
3ABD00024346 ACSM1-04CM-024A-4
3ABD00024347 ACSM1-04CM-031A-4
3ABD00024348 ACSM1-04CM-040A-4
3ABD00024349 ACSM1-04CM-046A-4
3ABD00024350 ACSM1-04CM-060A-4
3ABD00024351 ACSM1-04CM-073A-4
3ABD00024352 ACSM1-04CM-090A-4
ACSM1可选件（Options）
制动电阻（Braking Resistors）
3ABD68711401 JBR-01
3ABD68711410 JBR-03
3ABD68711428 JBR-04
3ABD68711436 JBR-05
3ABD68711444 JBR-06
可选适配器模块（Option Modules）
3ABD68805422 FEN-01
3ABD68805830 FEN-11
3ABD68805848 FEN-21
参见 FPBA-01
ACS350
输入电抗器（AC Mains Chokes）
3ABD68711185 CHK-01
3ABD68711193 CHK-02
3ABD68711215 CHK-03
3ABD68711231 CHK-04
3ABD68711240 CHK-05
3ABD68711266 CHK-06
3ABD68816238 CHK-07
3ABD68816246 CHK-08
主电源EMC滤波器（Mains Filter）
3ABD68711321 JFI-02
3ABD68711339 JFI-03
3ABD68711355 JFI-05
3ABD68711371 JFI-07
编程和维护工具（Programming and Maintenance Tools）
3ABD68748615 DriveStudio 1.x (Win2000/XP) incl. SPC and serial
connection cable OPCA-02
包括SPC编程软件和串口连接电缆OPCA-02
控制盘（Control Panels）
可选项代码
+J400 ACS-CP-A
DCS400系列通用型全数字直流变流器
输入电压: 三相 AC230V－500V 频率: 50/60Hz (模块价目中含DCS400-PAN控制盘、20A以下可调励磁单元)
DCS 401 2-quadrant converter 两象限
DCS401.0020
DCS401.0045
DCS401.0065
DCS401.0090
DCS401.0125
DCS401.0180
DCS401.0230
DCS401.0315
DCS401.0405
DCS401.0500
DCS401.0610
DCS401.0740
DCS401.0900
DCS 402 4-quadrant converter 四象限
DCS402.0025
DCS402.0050
DCS402.0075
DCS402.0100
DCS402.0140
DCS402.0200
DCS402.0260
DCS402.0350
DCS402.0450
DCS402.0550
DCS402.0680
DCS402.0820
DCS402.1000
DCS400变流器可选件
Line Reactor 进线电抗器
模块型号Converter Type
DCS 401.0020 DCS 402.0025
DCS 401.0045 DCS 402.0050
DCS 401.0065 DCS 402.0075
DCS 401.0090 DCS 402.0100
DCS 401.0125 DCS 402.0140
DCS 401.0180 DCS 402.0200
DCS 401.0230 DCS 402.0260
DCS 401.0315 DCS 402.0350
DCS 401.0405 DCS 402.0450
DCS 401.0500 DCS 402.0550
DCS 401.0610 DCS 402.0680
DCS 401.0740
DCS402.0820
DCS 401.0900 DCS 402.1000
主回路EMC滤波器 EMC filter for main thyristor bridge
DCS400模块(3x230V-500V AC)
模块型号Converter Type
230V-440V交流进线
DCS 401.0020 DCS 402.0025
DCS 401.0045 DCS 402.0050
DCS 401.0065 DCS 402.0075
DCS 401.0090 DCS 402.0100
DCS 401.0125 DCS 402.0140
230V-500V交流进线
DCS 401.0020 DCS 402.0025
DCS 401.0045 DCS 402.0050
DCS 401.0065
DCS 402.0075
DCS 401.0090 DCS 402.0100
DCS 401.0125 DCS 402.0140
DCS 401.0180 DCS 402.0200
DCS 401.0230 DCS 402.026
