品牌:大田
起订:1台
主机与料斗分体设计，安全、简便。
◎ 独立滤清装置，方便清除积尘。
◎ 不锈钢料斗。
◎ 微电脑操作控制程序。
◎ 过载、缺料报警。
◎ 700G采用高速整流马达，体积小、吸力强，适合用于新料输送。
◎ 800G、800G2采用感应式高压风机，噪音小、寿命长。
◎ 800G、800G2具有逆转自动清除粉尘功能。
◎ Host machine separated from the hopper,easy and safe to operate.
◎ Independent filter for easy cleaning.
◎ Stainless hopper.
◎ Microcomputer controlled.
◎ Alarm for overload and lack of material.
◎ High-speed rectificative motor of small footprint and strongsuction force for new material for AL-700G.
◎ Induction high-pressure pump of low noise and long service time for AL-800G/G2.
◎ Reverse cleaning for AL-800G/G2.
◎ 参数中的输送能力及吸料扬程是以SBS原料为测试材料得出的数据，实际参数根据塑料比重、形状及输送长度、高度、管路特性、参数设定等因素而改变。
◎ 吸料机在输送热料时，料管需选配耐160度高温料管。
◎ The parameters of the conveying capacity and suction lift are educed from tests on ABS.The actual parameters may be different due to the differences of the specific gravity and the shape of the material,the conveying distance and height,the specialty of pipeline and the seting of parameters.
◎ Heat-resistant(160℃)pipes should be used when conveying hot material
|
型号Model |
AL-700G |
AL-800G |
AL-800G2 |
|
|
马达Motor |
型式Type |
碳刷式Carbon brush |
感应式Induction |
感应式Induction |
|
规格Specification |
1KW/1.3HP1Ф |
1.1KW/1.5HP3Ф |
2.2KW/3PH3Ф |
|
|
输送能力（kg/h）Conveying capacity |
350-400 |
450-500 |
550-600 |
|
|
吸料扬程（m）Loading distance |
4 |
4 |
6 |
|
|
静风压（mm/H2O） Static wind pressure |
1550 |
1880 |
2400 |
|
