品牌:南澳电气
测试准确度:0.1%
最大分辨:1μΩ
起订:1套
供应:88888900套
发货:1天内
产品简介
NATS全自动多功能变压器综合测试台是南澳电气武汉公司根据《电力设备预防性试验规程》对电力变压器的试验要求，以及试验室试验要求而自生设计生产的最新产品。NATS变压器综合测试台具有功能齐全、结构紧凑、外形美观大方、通用性强和使用方便等特点，配置三台新仪器，可全自动打印输出。特别适用于电力系统、工矿企业、科研部门等对电力设备进行各种预防性试验。
产品别名
变压器特性综合测试台，变压器特性测试台，变压器综合试验台，变压器测试台，变压器试验台
产品特性
1．直流电阻测试
2．变比组别测试
3．空、负载损耗测试
4．工频耐压试验
产品参数
1.直流电阻测试
⑴ 测量范围：1μΩ~20KΩ
⑵ 测试电流：0.02Ω,0.2Ω 10A
2Ω 1A
20Ω 100mA
200Ω 10mA
2K Ω 1mA
20KΩ 0.1mA
⑷测试准确度:0.2% (满量程)
⑸显示方式:128*64点阵显示
⑹最大分辨:1μΩ
⑺电源:AC220V±22V,50HZ±2HZ
⑻功耗:200W
2.变比组别测试:
(1) 变比测量范围:1~10000
(2) 组别:1~12点
(3) 精度:1~1000 0.21级 1000~10000 0.5级
(4) 电源:AC220V±10%,50HZ
3.损耗测试:
(1) 电压:500V±(0.1%读数+0.1%量程)
(2) 电流:5A±(0.1%读数+0.1%量程)
(3) 功率:U*I±(0.1%读数+0.1%量程)
(4) 功率因数:0.0101.000±3个字
(5) 电源:AC220V±22V,50HZ±2HZ
(6) 整机功耗:小于15VA
4.工频耐压试验:
(1) 输入电压:两相380V
(2) 输出电压:0~430V
(3) 表计精度: ±0.5%
Product introduction
NATS Multi-function transformer testing bench is the latest products by Nanao Electric, according to "preventive test code for electrical equipment" of power transformer testing requirements, and laboratory tests and self-generated design and production requirements. NATS transformer integrated testbed with a full-featured, compact structure, elegant appearance, versatility and ease to use, equipped with three new instruments that can be printed out automatically. Especially suitable for power systems, industrial and mining enterprises, scientific research departments on a variety of electrical equipment preventive testing.
Also called name
transformer test bench, transformer test bed, integrated transformer test bed, transformer characteristic test bed
The Characteristics of the products
1.DC resistance testing
2.Turns ratio testing
3.no-load & load loss testing
4.Frequency voltage withstand testing
The parameters of the products
1. DC resistance test
⑴ measurement range :: 1μΩ ~ 20KΩ
⑵ testing current: 0.02Ω, 0.2Ω 10A
2Ω 1A
20Ω 100mA
200Ω 10mA
2K Ω 1mA
20KΩ 0.1mA
⑷ test accuracy: 0.2% (full scale)
⑸ Display: 128 * 64 dot matrix display
⑹ maximum resolution: 1μΩ
⑺ Power supply: AC220V ± 22V, 50HZ ± 2HZ
⑻ power consumption: 200W2.
2. Ratio group testing
(1) variable ratio measuring range: 1 to 10000
(2) Section: 1~12 point
(3) Accuracy: 1 ~ 1000 0.21 grade 1000 ~ 10000 0.5 grade
(4) Power supply: AC220V ± 10%, 50HZ
3. Loss Test
(1) Voltage: 500V ± (0.1% reading +0.1% of range)
(2) Current: 5A ± (0.1% reading +0.1% of range)
(3) Power: U * I ± (0.1% reading +0.1% of range)
(4) Power factor: 0.0101.000 ± 3 words
(5) Power supply: AC220V ± 22V, 50HZ ± 2HZ
(6) Power consumption: less than 15VA
4. Frequency voltage withstand testing
(1) Input voltage: 380V two-phase
(2) Output voltage: 0 ~ 430V
(3) Meter Accuracy: ± 0.5%
